Emerson introduces SIL 3-certified valve assemblies
Emerson has introduced the first valve assemblies that meet the design process requirements of Safety Integrity Level (SIL) 3 per the International Electrotechnical Commission’s IEC 61508 standard.
#VMAnews
Edited by Margo Ellis
Share
Emerson has introduced the first valve assemblies that meet the design process requirements of Safety Integrity Level (SIL) 3 per the International Electrotechnical Commission’s IEC 61508 standard. These Fisher Digital Isolation final element solutions serve the needs of customers for shutdown valves in critical safety instrumented system (SIS) applications.
Without this solution, users must specify all the individual valve components, procure each one, and assemble them into a working whole. Even if these steps are done correctly, this type of custom assembly will still not provide all the benefits of the Digital Isolation assembly.
“We were excited to work with Emerson to accomplish the first certified valve assembly,” said Loren Stewart, exida evaluating assessor for this project. “By providing a complete SIL solution for valve assemblies, Emerson is reducing unknown variables while helping ensure safety is always paramount.”
Engineering a safety shutdown valve is a complicated task. The normal and upset process conditions must be carefully evaluated and understood when choosing valve and actuator components. In addition, the proper combination of solenoids, brackets, couplings and other critical hardware must be specified and carefully matched to the selected valve. Each of these components must function individually and in concert to operate.
Emerson addresses these and other issues by providing an engineered Digital Isolation shutdown valve assembly, designed for each particular process. The various components are specifically selected to satisfy the application requirements. The entire assembly is sold as a fully tested and certified unit, with a single serial number and associated documentation delineating the details of every part of the assembly.
Because the assembly is built as a complete solution in Emerson facilities, it boasts a significantly improved probability of failure on demand (PFD) rate. In some cases, the failure rate of the assembly will be up to 50% less than the combination of the same valve components purchased individually and assembled by an end user.
